Features
Working pressure:
-
1 to 5 bar
Volume of water delivered (adjustable on request through PRESTO setting tool):
-
Small volume: 4l (+/- 1l) Adjustable from 2 to 6l at 2.5 bar
-
Large volume: 8l (+/- 1l) Adjustable from 4 to 9l at 2.5 bar
-
Volume preset at +/- 1.5l on pressure range from 1.2 to 4 bar
-
Anti-water-hammering device
-
Automatic 1 l/s flow limiter, from 1.2 to 4 bar dynamic working pressure
Operation:
-
Dual flush volume automatic detection depending on the time of user presence (4/6l - short/long detection)
-
By pass manual 6l push button (flush can be activated in case of power failure)
Power supply:
-
With mains 7V via 12V / 24V AC or DC. Compatible with 230 V AC / 12 V AC transformer not included (See Ref. 90464 / 90711 / 90610 / 90685 / 90704 / 90686)
Hydraulic supply:
-
On PRESTO 1000 XL tap with 3/4" (20x27) integrated stop valve
-
Outlet connection on flush pipe Ø 28 mm
Material and colour finish:
-
DZR Brass body and stop valve
-
Anti-vandal brushed stainless steel 304l front plate
Security:
-
Vacuum breaker device prevents the contamination of the water network from polluted water backflow
-
Patented anti-blocking "S" system to avoid the water to flow continuously
-
The solenoid valve will be closed automatically in case of low battery or any damage of detector
Delivered with:
-
1 concealed box
-
1 integrated stop valve
-
Instruction manual
Standards & approvals:
-
DZR Brass body in accordance with K UK Reg 4, certificate number 2204713, which verifies the requirements of "Regulation 4(1)a of the Water Supply (Water Fittings) Regulations 1999 England & Wales; 2009 Northern Ireland and 2014 Byelaws Scotland"
-
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
Specification
PRESTO 7100 XL N, mains power
